Original Factory Service Repair Manual for the Hitachi EX5500 Excavator.
Service Manual consists of the following two separate volumes:
Hitachi EX5500 Excavator Technical Manual
Hitachi EX5500 Excavator Workshop Manual
This manual is very detailed and contains all the official Hitachi manufacturer specifications, troubleshooting, repair instructions step by step with illustrations and wiring diagrams. Simple to complicated repairs can be completed effortlessly with the information provided. It is 100 percent complete and intact. The manual is specifically written for the DIY as well as the experienced mechanic.
CONTENTS AS FOLLOWS:
Workshop Manual Contents:
Section 1 – General Information
Group 1 Precautions for Disassembly and Assembly
Group 2 Tightening
Section 2 – Upperstructure
Group 1 Cab
Group 2 Pump Device
Group 3 Control Valve
Group 4 Swing Device
Group 5 Pilot Valve
Group 6 DQR Valve
Group 7 Pilot Shut-Off Valve
Group 8 Solenoid Valve
Group 9 Oil Cooler Fan Motor
Group 10 Compressor Drive Motor
Group 11 Air Conditioner
Section 3 – Undercarriage
Group 1 Travel Device
Group 2 Travel Brake Valve
Group 3 Drive Tumbler
Group 4 Center Joint
Group 5 Adjuster Cylinder
Group 6 Front Idler
Group 7 Upper/Lower Rollers
Group 8 Track
Group 9 Accumulator
Group 10 Welding Repair Procedure
Section 4 – Front Attachment
Group 1 Front Attachment
Group 2 Bushing and Point
Technical Manual Contents:
Safety
Section 1 – General
Group 1 Specification
Group 2 Component Specifications
Group 3 Component Layout
Section 2 – System
Group 1 Control System
Group 2 Hydraulic Circuit
Group 3 Electrical System
Section 3 – Component Operation
Group 1 Pump Device
Group 2 Swing Device
Group 3 Control Valve
Group 4 Pilot Valve
Group 5 DQR Valve
Group 6 Travel Device
Group 7 Others (Upperstructure)
Group 8 Others (Undercarriage)
Section 4 – Operational Performance Test
Group 1 Introduction
Group 2 Engine Test
Group 3 Excavator Test
Group 4 Component Test
Group 5 Standard
Section 5 – Troubleshooting
Group 1 Diagnosing Procedure
Group 2 Component Layout
Group 3 Troubleshooting A
Group 4 Troubleshooting B
Group 5 Troubleshooting C
Group 6 Electrical System Inspection Procedure
ATTACHED DIAGRAM LIST:
1. EX5500 ELECTRICAL CIRCUIT DIAGRAM 1/3
2. EX5500 ELECTRICAL CIRCUIT DIAGRAM 2/3
3. EX5500 ELECTRICAL CIRCUIT DIAGRAM 3/3
4. EX5500 CONNECTORS
5. EX5500 HYDRAULIC CIRCUIT DIAGRAM (BACKHOE) (Up to Serial No. 000106)
EX5500 HYDRAULIC CIRCUIT DIAGRAM (LOADING SHOVEL) (Up to Serial No. 000106)
6. EX5500 HYDRAULIC CIRCUIT DIAGRAM (BACKHOE) (Serial No. 000107 and later)
EX5500 HYDRAULIC CIRCUIT DIAGRAM (LOADING SHOVEL) (Serial No. 000107 and later)
———————-
Model Specification: Hitachi EX5500 Excavator
Language: English
File Format: PDF
Requirements: Adobe PDF Reader & WinZip
Zoom In/Out: yes
Notes: Bookmarked, searchable, Fully printable, instant download
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Smartphone, Android etc…
———————-
Pay Today and Download the complete manual instantly. The download link will also be sent to your e-mail. So please make sure your email address is correct. Don’t Forget to Check Spam / Junk if can’t find the new message in your email inbox immediately.
Thanks for Visiting.
