Original Factory Serviceman’s handbook for the Kobelco K903-II, K904-II, K904L-II, K905-II, K905LC-II, K907-II, K907LC-II, K909-II, K909LC-II, K912-II, K912LC-II, K916-II, K916LC-II Hydraulic Excavator.
This Serviceman’s handbook for the Kobelco hydraulic excavator provide maintenance and repair personnel with basic information concerning routine maintenance and repair of the kobelco machine. This handbook is compiled for the user’s handy convenience using extracts mainly from the operators and shop manuals.
for inspection and maintenance of the machine in the field, use this handbook as a reference to improve your work efficiency.
Models Covered:
K903-II
K904-II, K904L-II
K905-II, K905LC-II
K907-II, K907LC-II
K909-II, K909LC-II
K912-II, K912LC-II
K916-II, K916LC-II
Contents as Follows:
Specifications
Performance
Weight of Components
Lubrication Chart
Lubrication
Hydraulic Pressure
Hydraulic Circuits and Components
PQ Curve Pump
Dimensions For Attachment
Clearance Between Pin and Bushing
Travel Maintenance Standards
Hydraulic Cylinder
Electric System Diagram
Air System
Working Range of Attachments
Lifting Capacity
Components
———————-
Model Specification: Kobelco K903-II, K904-II, K904L-II, K905-II, K905LC-II, K907-II, K907LC-II, K909-II, K909LC-II, K912-II, K912LC-II, K916-II, K916LC-II Hydraulic Excavator
Language: English
Total Pages: 347
File Format: PDF
Requirements: Adobe PDF Reader
Zoom In/Out: yes
Notes: Bookmarked, searchable, Fully printable, instant download
Compatible: All Versions of Windows & Mac, Linux OS, Iphone, Ipad, Smartphone, Android etc…
———————-
Pay Today and Download the complete manual instantly. The download link will also be sent to your e-mail. So please make sure your email address is correct. Don’t Forget to Check Spam / Junk if can’t find the new message in your email inbox immediately.
